Specifications:

  • High-quality steel plating with minimum of 50,000 psi
  • Heavy-duty center pin with brass bushing and grease fitting plus
    access openings for ease of maintenance
  • New 30,000 lbs. capacity planetary rear-driving axle, solid
    mounted to chassis frame-John Deere 1200 series
  • New single speed hydra-static drive motor with in cab controls
  • New Spicer model 1710 drive line
  • New dual internal wet disc brakes on rear driving axle with
    parking brake and master controls in cab
  • New dual 3-1/2" x 12-1/8" articulated steering cylinders with in
    cab controls
  • New reinforced disc wheels with 17.5 x 25 grader-type tires - 14
    ply rating
  • New front axle components (spindles, hubs, bearings, seals, etc.
  • Front axle - oscillating type- non-powered
  • Paint - primed and finish coats to customer's specifications
  • 163" wheel base with extended front end tubular grapple
    transporting mount
  • 26' turning radius - articulated
  • Speed - 5 mph forward, 2 mph reverse
  • Gradability - 25% - low range only
  • All new construction and components
Hubler Bros., Inc. 4230 SPA can be retrofitted to any truck
mounted turntable loader (new or used), offering a greater
return on your investment.  This unit is manufactured,
assembled, and distributed exclusively by Hubler Bros.,
Inc.
Hubler Bros., Inc.
Product Fact Sheet: 4230 SPA
